Main Function:
The granular product feeding, metering, filling, bag formation, sealing, and date stamping operation is completed automatically by the machine.
Application:
Machine is suitable for different kinds of granule product packing. Like Hardwares, Plastic parts, Electronic parts, Candies, Medical pills, Medicinal tea, ect.
Liquid detergent
Chemical Liquid
Sauce & paste
Sticky jam
Medical liquid
Oil
Optional Bag Type
Machine use roll film to make big bags of pillow bag, standup pouch, gusset bag with hole punching, quad seal bag, ect.
3 sides seal bag
4 sides seal bag
Pillow bag
Linking bags
metering system:
Different metering pumps are available to accommodate various types of liquid product packaging. Examples include cylinder pumps, rotor pumps, and mechanical pumps.
Storage hoper
Mixer in hoper
Metering system
Main Machine Process
Film Input
The simple roll film structure allows film to flow in a steady and unimpeded condition.
Pillow Seal
Customised sealing and cutting structure for pillow stick bag seals.Bag width and bag length may be
3-side Seal
Customised sealing and cutting structure for the three-sided seal.Bag width and length can be adjusted within certain restrictions.
4-side Seal
Sophisticated sealing and cuting structure for 4-side seal.The molds are customized to meet a designed size.
Main Machine features
1.Customized volume cup sets for metering that can be modified in a specific range.
2.With HMI and a customised PLC system for simple parameter configuration.
3.A separate PID temperature controller is suited for a variety of packaging materials.
4.Basic construction is simple, making it easy to use and maintain.
5.Fully automatic filling, measuring, bag forming, and sealing.
6.Compact and portable for limited space.
7.The machine can begin operation without installation.
Different models is available for choice to meet differnt packing sizes.
| Model | AT-60L(stick bag) | AT-60L(3-side seal) | AT-60L(4-side seal) |
| Film width | Max.200mm | Max.200mm | Max.200mm |
| Bag width | 25~90mm | 30~100mm | 40~100mm |
| Bag length | 40~160mm | 40~160mm | 40~160mm |
| Measuring range | 1~50ml | 1~50ml | 1~50ml |
| Packing speed | 20~40 bags/min | 20~50 bags/min | 20~40 bags/min |
| Roll film diameter | 320mm | 320mm | 320mm |
| Film thickness | 0.04~0.08mm | 0.04~0.08mm | 0.04~0.08mm |
| Powder supply | 220V 50/60Hz, 2KW | 220V 50/60Hz, 2KW | 220V 50/60Hz, 2KW |
| Weight | 280KG | 280KG | 280KG |
| Machine size | 750×1150×1600mm | 750×1150×1600mm | 750×1150×1600mm |
*** Machine parameters can be customized according the packing requirements.
